Virtual Private Networking Using IPSec Connections
186
ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308
Note: Perform these tasks from a computer that has the NETGEAR
ProSafe VPN Client installed.
To configure the VPN client for Mode Config operation, create authentication settings (phase
1 settings), create an associated IPSec configuration (phase 2 settings), and then specify the
global parameters.
Configure the Mode Config Authentication Settings (Phase 1 Settings)
 To create new authentication settings:
1. Right-click the VPN client icon in your Windows system tray, and select Configuration
Panel. The Configuration Panel screen displays.
Figure 112.
2. In the tree list pane of the Configuration Panel screen, right-click VPN Configuration, and
select New Phase 1.
