Monitoring System Access and Performance
266
ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308
Figure 159.
2. Enter the settings for the WAN1 port as explained in the following table:
Table 65. WAN TrafficMeter screen settings
Setting Description
Enable Traffic Meter
Do you want to
enable Traffic
Metering on WAN1?
Select one of the following radio buttons to configure traffic metering:
• Yes. Traffic metering is enabled, and the traffic meter records the volume of
Internet traffic passing through the WAN1 interface. Complete the fields that are
shown on the right side of the screen (see explanations later in this table).
• No. Traffic metering is disabled. This is the default setting.
