Connecting the VPN Firewall to the Internet
39
ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308
Figure 21.
4. Configure the protocol binding settings as explained in the following table:
Table 7. Add Protocol Binding screen settings
Setting Description
Service From the drop-down list, select a service or application to be covered by this rule. If the
service or application does not appear in the list, you need to define it using the Services
screen (see Services-Based Rules on page 84).
Local Gateway From the drop-down list, select one of the WAN interfaces.
Source Network The source network settings determine which computers on your network are affected by
this rule. Select one of the following options from the drop-down list:
Any All devices on your LAN.
Single address In the Start IP field, enter the IP address to which the rule is applied.
Address Range In the Start IP field and End IP field, enter the IP addresses for the
range to which the rule is applied.
Group If this option is selected, the rule is applied to the selected group.
The group can be a LAN group or an IP (LAN) group.
Note: For information about LAN group, see Manage Groups and
Hosts (LAN Groups) on page 67. For information about IP groups,
see Create IP Groups on page 115.).
