The input and output signal of the Looper X will depend on its place in The Grid.
In1
Virtually places the looper in the Input block 1. The Looper X will receive input signal from
the Input 1 and its output will be affected by any Row assigned to this input block.
In2
Virtually places the looper in the Input block 2. The Looper X will receive input signal from
the Input 2 and its output will be affected by any Row assigned to this input block.
Ret1
Virtually places the looper in the Return 1. The Looper X will receive input signal from the
Return 1 and its output will be affected by any Row or FX Loop block assigned to this input.
Ret2
Virtually places the looper in the Return 2. The Looper X will receive input signal from the
Return 2 and its output will be affected by any Row or FX Loop block assigned to this input.
In1/2
Virtually places the looper in the Input blocks 1/2. The Looper X will receive input signal
from both Inputs 1/2 and its output will be affected by any Row assigned to these input
blocks.
Ret1/2
Virtually places the looper in the Returns 1/2. The Looper X will receive input signal from
both Returns 1/2 and its output will be affected by any Row or FX Loop block assigned to
these inputs.
Out1
Virtually places the looper in the Output block 1. The Looper X will receive input signal
from Rows using the Output block 1.
Out2
Virtually places the looper in the Output block 2. The Looper X will receive input signal
from Rows using the Output block 2.
Out3
Virtually places the looper in the Output block 3. The Looper X will receive input signal
from Rows using the Output block 3.
Out4
Virtually places the looper in the Output block 4. The Looper X will receive input signal
from Rows using the Output block 4.
Out1/2
Virtually places the looper in the Output blocks 1/2. The Looper X will receive input signal
from Rows using the Output blocks 1/2.
Out3/4
Virtually places the looper in the Output blocks 3/4. The Looper X will receive input signal
from Rows using the Output blocks 3/4.
Multi
Virtually places the looper in the Multi Out Block. The Looper X will receive input signal
from Rows using the Multi Out block.
