Nokia 7210 Configuration Guide

7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
3HE 17358 AAAB TQZZA © 2021 Nokia.
Use subject to Terms available at: www.nokia.com
541
Description This command allocates maximum resources for use by ingress filter policies using IPv4
criteria.
The resource cannot be shared with ingress filter policies using mac criteria or ipv6 criteria.
Refer to the 7210 SAS-M, T, R6, R12, Mxp, Sx, S Router Configuration Guide for more
information on resource allocation and fields available for use.
Ingress ACL resources are shared with SAP ingress aggregate meter. See the sap-
aggregate-meter command for more information.
The no form of this command specifies that the software does not allocate any resources for
use by ingress filter policies using ipv4 criteria. If no resources are allocated for use, the
software fails all attempts to associate a service entity (for example, SAP and IP interface)
with an ingress filter policy using this match criteria.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria.
If the user specifies max, the software allocates one chunk when the first SAP is
associated with an ingress filter policy using this match criteria. It continues to
allocate resources to SAPs associated with an ingress filter policy using this criteria,
as long as the total amount of resources allocated does not exceed the resources
allocated to ingress filter policies (configured with the config system resource-
profile ingress-internal-tcam acl-sap-ingress command) and chunks are
available for us.
Values Table 53 lists the parameter values.
Table 53 Number of Resources Available for IPv4-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 5 max
7210 SAS-T access-uplink mode (per node) 0 2 max
7210 SAS-T network mode (per node) 0 2 max
7210 SAS-R6 (per IMMv1) 0 7 max
7210 SAS-R6 and 7210 SAS-R12 (per IMMv2) 0 12 max
7210 SAS-R6 and 7210 SAS-R12 (per IMM-c) 0 9 max
7210 SAS-Mxp (per node) 0 10 max
7210 SAS-Sx 1/10GE (per node) (standalone) 0 6 max
7210 SAS-Sx 1/10GE (standalone-VC) 0 5 max
7210 SAS-S 1/10GE (per node) (standalone) 0 6 max
7210 SAS-S 1/10GE (standalone-VC) 0 5 max
