Installing cards in the 7360 ISAM FX-16 shelf
138
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
4 Slide the LT card into the appropriate LT card slot.
5 Press the insertion/extraction tabs on the front panel to lock the card in place. Attach fixation
screws located at the top and the bottom of the front panel of the card; see Figure 61.
Maximum torque: 2.66 lbf-in. (0.3 N.m).
6 The card first displays a heartbeat signal, that is, the green PWR LED is flashing. Then the
card displays an enabling operation signal:
• the green PWR LED is steady on
• the red ALM LED is off
7 In the same way, install all the planned LT cards for the shelf.
8 Install LT card dummy panels in any unused, unpopulated LT card slots to maintain proper
operation.
9 STOP. This procedure is complete.
Procedure 25 To remove cards
Use the following procedure to remove a card.
1 Put on the antistatic wrist strap and connect it to the earth bonding point at the bottom of the
7360 ISAM FX-16 shelf; see Figure 57.
2 Test the ESD wrist strap with the ohmmeter to ensure effectiveness; it must measure 1 MΩ
+/-20% to ground.
3 Loosen the fixation screws located at the top and the bottom of the front panel of the card.
4 Use the ejector handles to disengage the connectors from the backplane. Figures 62 and 63
show the different ejector handles on LT cards. Figure 64 shows the ejector handles on NT
cards.
Caution — When sliding the LT card into slot 9, ensure that the solder
side of the LT card does not come into contact with the EMC shielding
plate adjacent to the LT card slot. If not done properly, this may cause
damage at the solder side of the LT card.
