7360 ISAM FX-12 shelf cabling

174

ANSI Hardware Installation Manual

3HH-12893-AAAA-TCZZA Issue: 09

DRAFT

Figure 80 External frame ground point rear view

4 Perform power and ground tests as per local practices.

5 STOP. This procedure is complete.

10.5 Power cabling

This section describes the 7360 ISAM FX-12 general information, power distribution

unit location, and the external power cabling procedure to connect the power cables.

25880

Frame ground point

No. 2 AWG lug and 2 12-24 screws

(provided with the rack)

Frame ground point

(may be located on

the opposite side

on some racks)

Rack frame ground locations rear view
