Nokia 7360 ISAM FX-16 - Figure 28 Pre-Assembled 7360 ISAM FX-16 Heat and Fiber Baffle Kit; Figure 29 Mounting 7360 ISAM FX-16 Lower Heat and Fiber Baffle Kit

ANSI Hardware Installation Manual Installing a 7360 ISAM FX-16 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 91
DRAFT
Figure 28 Pre-assembled 7360 ISAM FX-16 heat and fiber baffle kit
7 Attach the heat and fiber baffle kit to the top of the 7360 ISAM FX-16 shelf using the provided
screws, as shown in Figure 29.
Figure 29 Mounting 7360 ISAM FX-16 lower heat and fiber baffle kit
23604
23913
