ANSI Hardware Installation Manual Fiber optic cable management in the 7360 ISAM
FX-12 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 211
DRAFT
12 Fiber optic cable management in
the 7360 ISAM FX-12 shelf
12.1 Overview
12.2 Managing fiber optic cables
12.3 Routing fiber optic cables
12.1 Overview
This chapter describes the fiber optic cable management and installation procedures
for the 7360 ISAM FX-12 shelf.
The fiber optic cable management strategy is based on the following concepts:
1 To route the fiber optic cables out of the rack toward the vertical cable channels
located on both sides of the front of the rack.
2 To route the fiber optic cables within the 7360 ISAM FX-12 shelf toward the
dedicated fiber outlets of the shelf.
3 To protect the fiber optic cables using optional bending protection items.
The 7360 ISAM FX-12 fiber optic cable management strategy incorporates the
following hardware:
• Fiber management bracket and fiber management guide to provide proper fiber
optic cable handling
Figure 108 shows a view of the fiber management bracket and Figure 109 shows a
view of the fiber management guide, with a close-up of one of the individual 3-slot
fiber guiding elements.
Note — See Appendix 27 “Fiber optic handling and acceptance
criteria”for more information.
