Figure 147 MDF cable POTS connection on 7360 ISAM FX-8

5 Secure the connector with standoffs and nuts.

6 Route and connect the other end of the cable as per site practices.

7 STOP. This procedure is complete.

14.12 Vectoring cable connector

This DLP provides the steps to connect vectoring links between a NDPS-B card and

NDLS-E cards.
