Installing a 7360 ISAM FX-4 shelf

322

ANSI Hardware Installation Manual

3HH-12893-AAAA-TCZZA Issue: 09

DRAFT

Figure 177 Location of 7360 ISAM FX-4 top and bottom mounting brackets

8 Attach the pre-assembled skirts and mounting bracket to the shelf using the M3 × 8mm

screws as shown in Figure 178.

Note — Torque the mounting bracket screws to 4.3 in. to 6.3 in. per lbs

after placing the skirt assembly onto the shelf.

Top mounting

bracket

Bottom mounting

bracket

23579
