Nokia 7360 ISAM FX-16 User Manual

ANSI Hardware Installation Manual Connector pinning of the external interfaces
Issue: 09 3HH-12893-AAAA-TCZZA 443
DRAFT
25.4 Remote craft port connector
Table 21 describes the remote craft port pinning for the 7360 ISAM FX-4,
7360 ISAM FX-8, 7360 ISAM FX-12 and 7360 ISAM FX-16 shelves.
Table 21 Remote craft port pinning for 7360 ISAM FX shelves
25.5 CO external alarm connector
Table 22 describes the CO external alarm pinning for the 7360 ISAM FX-4,
7360 ISAM FX-8, and 7360 ISAM FX-12 shelves.
SIG_GND Input 5 Electrical ground
1HZ_TIP Input 6 1 Hz signal tip input
TOD_RING Input 7 Time of day ring input
TOD_TIP Input 8 Time of day tip input
FG Input 9 Frame ground
FG Input 10 Frame ground
Signal name Type Pin number Description
(2 of 2)
Signal name Type Pin number Description
DCD Input 1 Data carrier detect
RXD Input 2 Receive data
TXD Output 3 Transmit data
DTR Output 4 Data terminal ready
Signal Ground Input 5 Signal ground
DSR Input 6 Data set ready
RTS Output 7 Request to send
CTS Input 8 Clear to send
RI Input 9 Ring indicator
