ANSI Hardware Installation Manual Overview
Issue: 09 3HH-12893-AAAA-TCZZA 35
DRAFT
2.2.2 GR-63-CORE indoor controlled environmental
space
GR-63-CORE indoor controlled environmental space requires:
• continuous, ambient operating temperature of 40°C measured at inlet air to shelf
• relative humidity of 5% to 85% non-condensing
• maximum altitude of 6 kft.
The 40°C operating temperature can be exceeded with a short-term, temporary
temperature up to 55°C measured at the air inlet, provided that the increase lasts for
a period of no more than 96 consecutive hours, and for a total of no more than
15 days a year, and that the environmental space does not exceed the maximum
yearly levels of contamination identified in Table 4.
Table 4 Maximum yearly levels of contamination — GR-63-CORE
indoor controlled environments
Note 1 — “15 days a year” refers to a total of 360 hours in any
given year, and no more than 15 individual occurrences during
a year.
Note 2 — A fan filter must be installed in the equipment and
replaced on a preventive maintenance schedule.
Contaminant or Oxide of Nitrogen Concentration
Airborne particles (TSP-Dichot 15) 20 μg/m
3(1)
Coarse particles <10 μg/m
3(1)
Fine particles 15 μg/m
3(1)
Water soluble salts 10 μg/m
3(1)
Sulfate 10 μg/m
3(1)
Nitrites 5 μg/m
3(1)
Volatile Organic Compounds 1200 ppb
(2)
(boiling point >30°C) 5000 μg/m
3(1)
Sulfur Dioxide 50 ppb
(2)
Hydrogen Sulfide 40 ppb
(2)
Ammonia 500 ppb
(2)
NO 500 ppb
(2)
NO2 200 pbb
(2)
HNO3 15 ppb
(2)
Ozone 125 ppb
(2)
Gaseous Chlorine (HCl +Cl2) 5 ppb
(2)
