ANSI Hardware Installation Manual Installing cards in the 7360 ISAM FX-8 shelf

Issue: 09 3HH-12893-AAAA-TCZZA 293

DRAFT

3 Use the ejector handles to engage the board connectors in the backplane.

4 Lock the board in place with the fixation screws located at the top and bottom of the faceplate

of the board; see Figure 158. The maximum torque is 0.6 Nm.

Procedure 62 To install NT cards

Use this procedure to install network termination (NT) cards in a 7360 ISAM FX-8 shelf.

A 7360 ISAM FX-8 has one or two NT cards:

• a single (first) NT card is inserted in slot NT-A

• a redundant card, if any, in slot NT-B

Figure 159 shows the 7360 ISAM FX-8 NT cards in the slots.

Note — Once the board is mounted in its slot, the green PWR LED lights

up.

Warning — For the 7360 ISAM FX-8, installation of NTIO cards must

be performed prior to installation of NT cards.
