NSW-5
General Information
PAMS Technical Documentation
Page 7
Issue 1 10/00
Nokia Mobile Phones Ltd.
Technical Specifications
General Specifications of Transceiver NSW-5
The NSW-5 is a dualband/dualmode radio transceiver unit fror the US
TDMA 800/1900MHz networks. The transceiver is fully based on 3V
technology.
The transceiver comprises the System/RF/keypad module (UT5U), the
LCD module and assembly parts.
The User interface consists of number, talk, soft and power keys in the
keymat. Instead of the normal up/down arrow keys, there is a Roller Key
with a selector switch. The display is a full graphic 96x65 pixel LCD.
The transceiver also comprises a Sliding cover over the keys. The Slid-
ing cover comprises a microphone.
The Antenna is of a fixed meander type. An external antenna connection
is provided by a top shoulder RF connector on the back.
The transceiver supports IR data transmission through the IR window on
the top of the phone.
Mechanical Characteristics
Unit Dimensions (W
x H x D) (mm)
Weight
(g) Typ.
Volume
(ccm)
Notes
Transceiver 53 x 125 x 22 95 90
Transceiver with BLS-2S
900mAh Li-Ion battery
53 x 125 x 25 140 125
BLS-2S battery pack 900mAh 45 x 103 x 10 45 35 Li-Ion prismatic
BLS-2N battery pack 900mAh 45 x 103 x 10 50 41 Li-Ion prismatic
BMS-2S battery pack 900mAh 45 x 103 x 12 72 46 NiMH 3x5/3AAA
BMS-2V battery pack 900mAh 45 x 103 x 14 76 52 NiMH 3x5/3AAA with
Vibra
Temperature range
Performance Temp range Comments
Ambient -30 ... +60 ° C Specification fulfilled, IS-55, Class B, IS-137
Internal -30 ... +85 ° C Limited by MCU SW
Battery, internal -30 ... +45 ° C Charging limit
