NSW-5
Service Software Instructions
PAMS Technical Documentation
Page 12
Issue 1 10/00
Nokia Mobile Phones Ltd.
Menu Bar
The Service Software package includes two menu bar configurations. The
first is an abbreviated version that contains the minimum number of me-
nus that allows package configurations when a phone is NOT connected.
The second is described below:
The menu bar MUST only contain the following menus for the Service
Software package when a phone is connected:
• P
roduct*
• C
onfigure*
• T
uning
• Te
sting
• S
oftware
• D
ealer
• V
iew
• H
elp* (* – always displayed, even if no phone is connected).
A menu is broken down into sections that are indicated with menu separa-
tors. Each sections identifies a logical difference from itself and other sec-
tions, i.e. between transmitter and receiver. Any items that are required to be
added to a menu lists will be added on the bottom of the appropriate menu
section list. If a new item is to be added which is common to two or more
phone types, then that menu item will become a common menu item.
The menu lists will use the Microsoft [...] symbol after an item name to in-
dicate that selecting that item will NOT initiate an operation immediately,
i.e. a dialog box will be displayed for the user to select options or type in
data and press the OK button before the operation is performed.
Product
The Product menu contains the following menu items:
• N
ew Ctrl+R
• O
pen...
• C
lose
• I
nitialise
• Normal Mode F5
• Local Mode Shift+F5
•F
aultlog
• Activate Faultlog... F9
• Edit Faultlog...
•Fast N
AM (available only if fastNAM installed)
