NSW-5
Tuning and Flashing Instructions
PAMS Technical Documentation
Page 6
Issue 1 10/00
2000 Nokia Mobile Phones Ltd.
Flash Concept for NSW-5, using FLA-7
3.
4.
5.
6.
7A.
8.
9.
1.
2.
7B.
10.
11.
12.
3.
4.
5.
6.
7A.
8.
9.
14.
12.
13.
Item: Service accessory: Type Product code:
1 Service Battery BTD-3 0670280
2 Flash Loading Adapter FLA–7 0770119
3 Flash Security Box TDF–4 0770106
IR Module JLP–1 for TDF–4 0750079
4 Prommer FPS–4S (Sales Pack Americas) 0081275
5 D15 – D15 Cable AXS–5 0730091
6 Printer Cable
(Included in FPS–4S Sales Pack) 0730029
7A D9 – D9 Cable AXS–4 (Included in FPS–4S Sales Pack) 0730090
7B D9 – D9 Cable AXS–4U 0730163
8 Service Cable XMS–3 0730174
9 Software protection key PKD–1 0750018
10 Service SW diskette 3.5” for NSW-5 0775229
11 Travel Charger ACH–6E (Euro) 0270381
Travel Charger ACH–6U (USA) 0675085
Travel Charger ACH–6X (UK) 0270380
12 AC Charger ACL–3E for 220V 0680015
13 Service Cable SCH-5A 0730166
14 Power Cable SCF–7 0730141
