IR Test... command
A Combox and the infrared thes modlue JLP–1 are needed for this test.
Activation Status Bar Text
Alt, E,I IR module test
Command is used for making IR module test. Function opens IR Test dia-
log:
Dialog mode: modal
IR Test dialog has following items:
Result box:
Result can be OK/FAILED
Test button (ALT+T):
Starts the IR Test.
Close button (ENTER):
Closes the IR Test dialog.
Help button ( Alt+H)
Context sensitive help
