Nokia NSW-5 Series - Assembly Parts of NSW-5 NX

NSW-5
Product Variants
PAMS Technical Documentation
Page 7
Issue 1 10/2000
 Nokia Mobile Phones Ltd.
Assembly Parts of NSW-5NX
ITEM Q’TY CODE DESCRIPTION VALUE, TYPE
I001 9497058 Slide cover assembly
I002 9497009 Slide assembly DMC01314
I003 (varia) Logo label
I004 9451486 A–cover assembly DMC01461
I005 9790342 Power Keymat/Speaker gasket DMC01487
I006 5200017 Slide sensor switch DMC01259
I007 5200013 Roller key assembly 10v 1ma
I008 9794014 Keymat module DMC01847
I009 5140067 Speaker + spring 103+–3DB
I010 9480401 Display assembly DMC01299
I010 0201142 Radio module UT5U
I012 5140123 Buzzer with gasket 100dB
I013 4700089 RTC battery polyacene 2.3 mAh 3.3V
I014 4 6290073 Screw M1.8x8 T6 remf. blk dmd03671
I015 9456335 B–cover assembly DMC01835
I016 2 6290079 Screw M1.8x11 T6 dmd04746
I017 9460299 Elastic plug DMD04645
I018 0660198 Antenna fxd 824–894/1850–1990mhz
I019 9451139 Dust Cap DMD02859
I020 9456920 Window assembly
