NSW-5
Disassembly and Troubleshooting Instructions
PAMS Technical Documentation
Page 39
Issue 1 10/00
 Nokia Mobile Phones Ltd.
Check current
consumption
I: >700 mA
AMPS, PL2, CH383
Y
N
Check Antenna Circuit
and Duplex–filter.
Short–circuits in PA?
Press down PA
Inreasing current
consumption ?
Note!
Check all supply voltages and solderings
Check also N900 pin3 frequency and
input power. Should be > –8 dBm and
f = 997.68 MHz. If not start synth trouble
shooting (TX–LO is missing)
Change PA
Check possibility for
delamination
Check gain control
voltage at C720
V: >2.2 V
Y
N
Check PA input PWR
P: > 0 dBm
Change PA
Y
Y
N
N
Check Z901 filter
insertion loss
<4dB
Check R903 and
C913
Y
N
Check TXC
V: >1.5 V
Y
Start Power control
troubleshooting
Check Cobba
TXCDAC
(BaseBand)
N
TX driver input power
P: > –20 dBm
Change driver N902
Y
N
Delamination means, that the
chip has loosened inside the
package during reflow.
In AMPS mode PA pin 16 bias–
Voltage should be > 2.2V.
