Nokia NSW-5 Series

NSW-5
System Module UT5U
PAMS Technical Documentation
Page 41
Issue 1 10/00
 Nokia Mobile Phones Ltd.
UnitMaxTyp/
Nom
MinParameter
Mixer output 1dB compr. point 0.8 V
pp
Gain of the last IF buffer 34 36 38 dB, single ended
Max IF2–buffer output level 1.4 V
pp
IF2–buffer output impedance 300 ohm, single ended
Transmitter
RF Characteristics of the transmitter:
Item DAMPS TDMA1900
TX frequency range 824.01...848.97 MHz 1850.01...1909.95 MHz
Type
Upconversion
Intermediate frequency 161.19 MHz 196.23 MHz
Nominal power on highest power level 0.48W (26.8 dBm) 0.355W (25.5 dBm)
Power control range 65 dB
Maximum rms error vector 12.5 %
Synthesizers
Output levels
Parameter Min Typ/
Nom
Max Unit
2G UHF synthesizer to Lo buffer
level
resistive load
parallel capacitance
–7
tbd
tbd
dBm
Ω
pF
1G UHF synthesizer to TX mixer
level
impedance
–2
tbd
dBm
Ω
VHF synthesizer to EROTUS
level
resistive load
parallel capacitance
100
1k
tbd
mV
pp
Ω
pF
VCTCXO 19.44 MHz
level
resistive load
parallel capacitance
600
1k
20
mV
pp
Ω
pF
