Nordmann Engineering AT4 D - Menu Navigation and Settings Levels; Menu Structure Overview; Settings Levels (User, Engineering, Diagnostic)

19
User Code
3562
Enter Number
Conrm with Set
Esc Set
User
Settings :Set
Modbus :Set
Maintenance :Set
Esc Set
Diagnostic
Unit Status :Set
Bath Test :Set
Remote Test :Set
ErrorHistory:Set
Module Test :Set
Esc Set
Menu overview
Menu User
– Resetting the maintenance counter
– Unit settings
– Modbus settings
Menu Engineering
The engineering level requires special knowledge and may
only be served by a Nordmann service technician.
Menu Diagnostic
– Interrogation of the malfunction list
– Interrogation of unit information
– Carrying out steam bath tests
– Carrying out relay tests
– Carrying out unit tests
Main Menu
Operat.Mode :Manual
Duration :45min
Fragrance :Set
Setpoint :48°C
Light-2 :O
Esc Set
Main Menu
Light-2 :O
User :Set
Engineering :Set
Fragrance :Set
Diagnostic :Set
Esc Set
Main Menu
Light-2 :O
User :Set
Engineering :Set
Fragrance :Set
Diagnostic :Set
Esc Set
Main Menu
Light-2 :O
User :Set
Engineering :Set
Fragrance :Set
Diagnostic :Set
Esc Set
Indication level
Menu level
Modifying temperature setpoint (steam bath operation) or humidity setpoint
(caldarium operation)
Setting steam bath mode
Setting operating time in steam bath mode
Fragrance pump settings
Setting operating behaviour of light output 2
Menu
AT4D 65kg/h 400V3
Steam Bath :Standby
Temperature :34°C
Setpoint :48°C
2011-08-31 12:00:00
Light Start
Display steam bath operation Display caldarium operation
Menu Licht Start
AT4D 65kg/h 400V3
Steam Bath :Standby
Humidity :44.7%rH
Setpoint :45%rH
2011-08-31 12:00:00
