18
5 Working with the unit control
Note: if you are working with the optional remote terminal read chapter 5.6
“Working with the remote terminal” rst. The operation of the remote
terminal deviates in some points from the operation at the steam generator
and some adjustments are blocked via the remote terminal for safety reasons.
5.1 Operating the control unit and menu overview
Operating
The operating and display unit is operated via the four keys located just
below the display. The 4 status elds at the bottom of the display show the
active keys the functions assigned to them.
actual key setting
keys
Menu
AT4D 65kg/h 400V3
Steam Bath :Standby
Temperature :34°C
Setpoint :48°C
2011-08-31 12:00:00
Light Start
