5.5.4 Performing remote relay tests
Select the remote test:
Path: Main Menu > Diagnostic > Remote Test
The list with the remote relay tests appears, the rst relay test (steam) is shown.
Press the < > and < > keys in order to select the further relay tests available and press the <Set> key
to activate/deactivate the corresponding relay for testing.
5.5.5 Performing Module tests
Note: this function is not available via the optional remote terminal.
Select the Module tests:
Path: Main Menu > Diagnostic > Module Test
The list with the module tests appears, the rst test (Inlet Valve) is shown.
Press the <
> and < > keys in order to select the further module tests and press the <Set> key to
activate/deactivate the corresponding component for testing.
