Nordmann Engineering AT4 D - Modbus Settings; Modbus Network Configuration; Modbus Address and Parity

44
5.4 Modbus settings
Select the Modbus menu:
Path: Main Menu > User > Password entry: 3562 > Modbus
In the Modbus submenu you can set the parameters for Modbus networks or for the communication
with the optional remote terminal. Detailed information on the different settings are found in the follow-
ing chapters.
5.4.1 Settings for Modbus networks
Select “Networking” in the Modbus submenu, then press the <Set> key. In the upcoming modication
dialogue adjust the settings for the Modbus network operation.
Settings:
• “Modbus Addr.”: Modbus address of the steam generator
(Factory setting: 1, Setting range: 1...247).
• “Parity”: Parity bit for the data transmission
(Factory setting: None1, Options: None1, None2, Odd, Even)
Note: for Modbus network operation the baud rate is set to 9600 baud as standard.
User
Settings :Set
Modbus :Set
Maintenance :Set
Esc Set
Modbus
Remote :Set
Networking :Set
Esc Set
Networking
Parity :None1
Mode Addr. :1
Esc Set
Networking
Parity :None1
Mode Addr. :1
Esc Set
Networking
Parity :None1
Mode Addr. :1
Esc Set
Modbus Addr.
1
1
Esc Set
Modbus
Remote :Set
Networking :Set
Esc Set
Parity
None1
None2
Odd
None1
Even
Esc Set
User Code
3562
Enter Number
Conrm with Set
Esc Set
Main Menu
Light-2 :O
User :Set
Engineering :Set
Fragrance :Set
Diagnostic :Set
Esc Set
Menu Light Start
AT4D 65kg/h 400V3
Steam Bath :Standby
Temperature :34°C
Setpoint :48°C
2011-08-31 12:00:00
