9 Productspecications
9.1 Technical data
Steam capacity in kg/h 5 8 15 23 32 45 65
Capacity range in kg/h 1...5 1.6...8 3...15 4,6...23 6,4...32 9...45 13...65
Nominal power in kW 3,8 6,0 11,3 17,3 24,0 33,8 48,8
Heating voltage 230V/1~/50..60Hz *
Unit model 522 822
Nominal current in A 16,3 26,1
Steam cylinder type ** 522A 822A
Heating voltage 400V/2~/50..60Hz *
Unit model 524 824
Nominal current in A 9,4 15,0
Steam cylinder type ** 524A 824A
Heating voltage 230V/3~/50..60Hz *
Unit model 532 832 1532 2362 3262
Nominal current in A 9,4 15,1 28,2 43,3 60,2
Steam cylinder type ** 532A 832A 1532A 2362A 3262A
Heating voltage 400V/3~/50..60Hz *
Unit model 534 834 1534 2364 3264 4564 6564
Nominal current in A 5,4 8,7 16,2 24,9 34,6 48,7 70,4
Steam cylinder type ** 534A 834A 1534A 2364A 3264A 4564A 6564A
Steam cylinder type ***
534A-L 834A-L 1534A-L 2364A-L 3264A-L 4564A-L ---
Control voltage 230 V/1~/50..60 Hz
Operating conditions
Admissible water pressure 1...10 bar
Water quality Untreated drinking water with a conductivity of 125...1250 µS/cm
Admissible water temperature 1...40 °C
Admissible ambient temperature 1...40 °C
Admissible ambient humidity max. 75 %rF (non condensing)
Admissible air pressure in the steam bath cabin
-0.8 kPa...1.5 kPa
Type of protection IP21
Conformity CE, VDE, GOST
Dimensions/Weights
Width in mm 428 428 508 508 563 563 563
Height in mm 575 575 620 620 640 640 640
Depth in mm 255 255 345 345 354 354 354
Net weight in kg 12 19 28 30
Operating weight in kg 17 29 65 67
Water supply connector G 3/4" (male thread)
Water drain connector ø 31 mm (outside diameter)
Steam connector 1x ø 22 1x ø 35 2x ø 35
Options
Cable gland 1x CG
Steam hose connector with condensate trap 1x CT22 1x CT35 2x CT35
Internal control voltage supply
1x S-CVI 1x M-CVI 1x L-CVI
@Link AT4 D @Link AT4 D
Accessories
Filter valve 1x Z261
Nordmann AT4 D Remote Terminal RP
Nordmann AT4 D Touch Screen Panel TSP
Temperature sensor KTY KTY
Steam distributor 1xW22 1xW35 2xW35
Fragrance pump 1xFP 240V
T-piece for fragrance injection 1xTSD22 1xTSD35 2xTSD35
Steam hose / meter 1xDS22 1xDS35 2xDS35
Condensate hose / meter KS10
Condensate drain 1xCD22 1xCD35 2xCD35
EcoTherm insulation hose 1xECT22 1xECT60 2xECT60
50-210VA transformer for 4x50W lamps TRL
* Other heating voltages on request
**
Steam cylinder for water conductivity from 125 to 1250 µS/cm (standard version)
*** Steam cylinder for low water conductivity from 80 to 125 µS/cm
