7.2 Malfunction lists
Important! Most operational malfunctions are not caused by faulty equipment
but rather by improper installation or disregarding of planning guidelines.
Therefore, a complete fault diagnosis always involves a thorough examina-
tion of the entire system. Often, the steam hose connection has not been
properly executed, or the fault lies with the humidity control system.
7.2.1 System faults
Warning Error Cause Remedy
LED Display LED Display
CF card missing
(Test run possible)
––– ––– red
lights
Error
E1: CF card Missing
No CF card installed on the control board. Install CF card or start test run.
CF card is empty
––– ––– red
lights
Error
E2: CF card Empty
No data stored on the CF card. Install new CF card.
CF card is defective
––– ––– red
lights
Error
E3: CF card Invalid
Invalid data stored on the CF card. Install new CF card.
CF card is incompatible
––– ––– red
lights
Error
E4: CF card incompat
The installed CF card is not compatible with
the hardware of the unit or with the basic
settings of the control electronics.
Install correct CF card. Let your Nord-
mann service technician adjust the basic
settings.
Steam bath board not connected
––– ––– red
lights
Error
E5: Module W Missing
Steam bath board not connected to the
control board, the system does not start.
Connect steam bath board to the control
board.
Hardware fault
––– ––– red
lights
Error
E10: Flash R/W Fault
Control board defective. Replace control board.
––– –––
Error
E11: Clock R/W Fault
Backup battery on control board
discharged.
Let have the backup battery be replaced
(see chapter 7.5).
Max. heating time exceeded
––– ––– red
lights
Error
E13: Max Heating
Steam bath was in operation too long. Check week timer.
Increase maximum heating time.
Steam bath door open too long
––– ––– red
lights
Error
E14: Door open
Steam bath door was open too long. Close steam bath door.
Check door switch.
If no door control is connected: Check
whether a cable bridge is connected on
the corresponding contacts on the steam
bath board.
Program fault
––– ––– red
lights
Error
E15: Program Fault
Program fault, steam generator is
blocked.
Please contact your Nordmann supplier.
Test Mode active
–––
Warning
W16: Test Mode Active
––– ––– Diagnostic mode active (Remote Test,
Module Test etc.)
Quit diagnostic mode.
