Nordson Encore Series User Manual

Description
3-1
Part 1612500−02
E 2018 Nordson Corporation
Section 3
Description
Introduction
See Figure 3-1. This manual covers all versions of the Encore PE Manual
Powder Spray System:
S Mobile system with feed hopper
S Rail-mount system
Controller with Rail Mount Installed
Spray Gun
Mobile System with Feed Hopper
Pump
Pump
Mount
Hopper
Figure 3-1 Encore PE Manual Powder Systems

Nordson Encore Series Specifications

General

Maximum Output Voltage	100 kV
Power Source	Electric
Maximum Powder Output	20 lbs/hr (9.07 kg/hr)
Air Consumption	10-15 CFH (4.7-7.1 L/min)
Application	Powder coating
Technology	Electrostatic
Maximum Flow Rate	20 lbs/hr (9.07 kg/hr)
Weight	1.5 lbs (0.68 kg)
