Nordson Encore Series User Manual

Parts
7-8
Part 1612500−02
E 2018 Nordson Corporation
Front Panel and Internal Cabinet Ground Parts List
Refer to Figure 7-22.
Item Part Description Quantity Note
− 1107552 CONTROLLER ASSY, manual, Encore LT,
packaged
1
1 1108279
S KIT, PCA, control, Encore LT
1
2 1108312
S PANEL, keypad, Encore LT/auto controller,
packaged
1
3 982916
S SCREW, flat, socket, M5 x 10, black
4
4 982636
S SCREW, button, socket, M5 x 12, zinc
2
5 983127
S WASHER, lock, internal, M5, zinc
2
6 983403
S WASHER, lock, split, M4, steel, zinc
4
7 982881
S SCREW, pan head, recessed, M4 x 6, zinc
2
8 1045837
S SCREW, pan head, recessed, M5 x 12
w/lockwasher, black
2
9 984702
S NUT, hex, M5, brass
1
10 983401
S WASHER, lock, split, M5, steel, zinc
1
11 983021
S WASHER, flat, 0.203 x 0,406 x 0.040, brass
1
12 933469
S LUG, 90, double, 0.250, 0.438 in.
1
13 240674
S TAG, ground
1

Nordson Encore Series Specifications

General

Maximum Output Voltage	100 kV
Power Source	Electric
Maximum Powder Output	20 lbs/hr (9.07 kg/hr)
Air Consumption	10-15 CFH (4.7-7.1 L/min)
Application	Powder coating
Technology	Electrostatic
Maximum Flow Rate	20 lbs/hr (9.07 kg/hr)
Weight	1.5 lbs (0.68 kg)
