Description
3-2
Part 1612500−02
E 2018 Nordson Corporation
Mobile System Components
Mobile systems include:
S Encore LT manual controller
S Encore PE manual spray gun
S Encore PE powder feed pump
S 50-lb Encore round feed hopper with PE pump mount assembly
S 1/2 in. powder hose, air tubing, spiral wrap, and Velcro straps
The components are mounted on a sturdy two-wheeled dolly.
Rail-Mount System Components
Rail-mount systems include:
S Encore LT manual controller
S Encore PE manual spray gun
S Encore PE powder feed pump
S PE pump mount assembly for use with feed hoppers
S Rail-mount bracket kit
S Grounding kit
S 1/2 in. powder hose, air tubing, spiral wrap, and Velcro straps
S Air filter kit
Specifications
Model Input Rating Output Rating
ENCORE Applicator +/− 19 VAC, 1 A 100 KV, 100 μA
ENCORE Controller 100−250 VAC, 50/60 Hz N/A
S Input Air: 4.0−7.6 bar (58−110 psi), <5μ particulates, dew point <10 _C
(50 _F)
S Max Relative Humidity: 95% non-Condensing
S Ambient Temperature Rating: +15 to +40 _C (59−104 _F)
S Dust Ingress Protection: IP6X
This applicator and controller are used with Porcelain Enamel powders
which are non-flammable.
Mobile System with 50Lb. Feed Hopper
Height: 995 mm (35.2 in.)
Length: 812 mm (32 in.)
Wheel Base: 598.5 mm (23.5 in.)
Weight: 51.5 kg (114 lbs)
