Parts
7-12
Part 1612500−02
E 2018 Nordson Corporation
System Components and Parts
System Components and Kits
Item Part Description Quantity Note
NS 1602269 ASSEMBLY, pickup tube, Encore PE 1
NS 1604292 HOPPER assembly, NHR Encore PE, 50 lb,
packaged
1
NS 1107552 CONTROLLER, manual, Encore LT, packaged 1
NS 1602268
PUMP assembly, 90_, Encore PE
1
NS 1107913 KIT, rail mount, Encore LT 1
NS 1067694 KIT, ground bus bar, ESD, 6 position, w/hardware 1
NS 1600658 HANGER, gun, Encore LT 1
NS 1600566 KIT, filter, Encore LT 1 A
NS 1600608
S FILTER, mist separator, 0.3 micron, 1/2 in. NPT
1
NS 1600609
SS FILTER ELEMENT, separator, 0.3 micron
1
NS 1604487 VALVE, flow control, 4-mm tube x 4-mm tube 1 B
NOTE A: Filter kit includes fittings and mounting bracket.
D: Connect to air wash connector on controller rear panel to control air flow.
NS: Not Shown
Powder Hose and Air Tubing
Note the minimum quantity of tubing before ordering.
Part Description Note
900617 Air tubing, polyurethane, 4 mm, clear A
900742 Air tubing, polyurethane, 6 mm, blue A
900741 Air tubing, polyurethane, 6 mm, black
900618 Air tubing, polyurethane, 8 mm, blue A
900619 Air tubing, polyurethane, 8 mm, black A
900740 Air tubing, polyurethane, 10 mm, blue A
900724 Tubing, powder, polyurethane, 0.485, clear B
900517 Tubing, poly, spiral cut, 0.62 in. ID
301841 Strap, Velcro, w/buckle, 25 x 3 cm
NOTE A: Minimum order quantity is 50 ft. (15.24 m).
E: Powder feed hose. Minimum order is 25 ft. (7.62 m).
