Operation
4-7
Part 1612500−02
E 2018 Nordson Corporation
Classic Flow Mode Settings
To use Classic Flow mode, the controller must be configured for it. Refer to
page 2-11 for a list of the mode defaults and configuration instructions.
sets the flow air pressure
sets the atomizing air pressure.
Setting values for both are 0−99% of maximum air pressure. Press the +
and − buttons to enter the desired setpoint. The longer a button is pressed
the faster the units change.
At 7 bar (100 psi) supply pressure:
Flow
Setting %
Atomizing
Setting %
Flow Air Pressure
bar (psi)
Atomizing Air Pressure
bar (psi)
25 25 1.7 (25) 1.7 (25)
40 10 2.7 (40) 0.689 (10)
In other words,
If Flow air = 25%, Atomizing air = 25%, then
Flow air = 1.7 bar (25 psi), Atomizing air = 1.7 bar (25 psi).
If Flow air = 40%, Atomizing = 10%, then
Flow air = 2.7 bar (40 psi), Atomizing air = 0.689 bar (10 psi).
Refer to your pump manual for typical operating values for Flow and
Atomizing air.
