Nordson Encore Series User Manual

Parts
7-7
Part 1612500−02
E 2018 Nordson Corporation
Controller Parts
Front Panel and Internal Cabinet Ground Parts Illustration
1
2
3
5
4
7
6
9
10
11
12
13
Rear Panel Assembly
See Figures 7-23 and 7-24 for
parts
8
Figure 7-22 Controller Parts

Nordson Encore Series Specifications

General

Maximum Output Voltage	100 kV
Power Source	Electric
Maximum Powder Output	20 lbs/hr (9.07 kg/hr)
Air Consumption	10-15 CFH (4.7-7.1 L/min)
Application	Powder coating
Technology	Electrostatic
Maximum Flow Rate	20 lbs/hr (9.07 kg/hr)
Weight	1.5 lbs (0.68 kg)
