Nordson Encore Series User Manual

Troubleshooting
5-5
Part 1612500−02
E 2018 Nordson Corporation
Corrective ActionPossible CauseProblem
12. More than one key on
the keypad quits
working when
pressed
Flex connection from the keypad
to the main board is not seated
properly
Loosen and re-seat the flex circuit on
the main board, making sure the flex
cable is fully inserted into the
connector.
To loosen the flex circuit, gently pull
the black bar on the cable connector
away from the white connector. This
will allow you to adjust the flex cable
to ensure proper seating. The cable
should be inserted past the white line
marked towards the end of the cable.
Push the black bar back into the
white connector to secure.

Nordson Encore Series Specifications

General

Maximum Output Voltage	100 kV
Power Source	Electric
Maximum Powder Output	20 lbs/hr (9.07 kg/hr)
Air Consumption	10-15 CFH (4.7-7.1 L/min)
Application	Powder coating
Technology	Electrostatic
Maximum Flow Rate	20 lbs/hr (9.07 kg/hr)
Weight	1.5 lbs (0.68 kg)
