NORMALAB NDI 450 - 2 Structure of the machine

NORMALAB France
2012
N O R M A L A B F r a n c e
2/118
1 CONTENTS
1 CONTENTS 2
2 STRUCTURE OF THE MACHINE 6
2.1 MECHANICAL STRUCTURE 6
2.1.1 HEATING BLOCK 6
2.1.2 SUBSET COMPARTMENT 6
2.1.3 SUBSET CONDENSER 7
2.1.4 THE VENTILATION 7
2.2 ENVIRONNEMENT OF THE MACHINE 8
2.3 ELECTRONIC STRUCTURE 9
2.3.1 ELECTRONIC STRUCTURE 9
2.3.2 LOCATION OF THE ELECTRONIC BOARDS 9
2.3.3 THE EXTERNAL CONNECTIONS 11
3 INSTRUCTION SHEETS 12
3.1 ACCESS TO PARTS OF THE MACHINE 12
3.1.1 OPENING THE PANELS 12
3.1.2 REMOVING THE FRONT PANEL 13
3.1.3 ACCESS TO THE ELECTRONIC DRAWER 15
3.2 LEVEL FOLLOWER 16
3.2.1 REPLACEMENT OF THE 1RST DROP OPTICAL SENSOR 16
3.2.2 REPLACEMENT OF THE FOLLOWER OPTICAL SENSOR 17
3.2.3 REPLACEMENT OF THE LIMIT SWITCHES OF FOLLOWER 18
3.2.4 REPLACEMENT OF DRIP DEFLECTOR DETECTOR 19
3.2.5 REPLACEMENT OF STEP BY STEP MOTOR 22
3.2.6 REPLACEMENT OF THE MOTOR BOARD 24
3.2.7 REPLACEMENT OF DETECTOR OR MAGNET OF COMPARTMENT DOOR 25
3.3 HEATING BLOCK 26
3.3.1 REPLACEMENT OF THE HEATING ELEMENT 26
3.3.2 REPLACEMENT OF TURBINE 27
3.3.3 REPLACEMENT OF FIRE DETECTION THERMOCOUPLE 28
3.3.4 REPLACEMENT OF VAPOR PROBE’S DETECTOR 29
3.3.5 REPLACEMENT THE MECHANICAL SYSTEM OF SAMPLE PROBE DETECTION 30
3.3.6 REPLACEMENT OF HEATING BLOCK DOOR’S DETECTOR 30
