N O R M A L A B F r a n c e
70/118
o PT 100 probes
o Thermocouples
o Drip deflector sensor
o Liquid detector of expansion tank
o Door sensor of heating block
o Door sensor of compartment
o Limit switches of level follower
o Optical sensor ( first drop and follower)
- Manage the I/O relay:
o General power supply
o Powering Peltier and stepper motor power supply
o Heating block relay
o Turbine of heating block
o Drive the stepper motor board
o Hot/cold compartment
o Hot/cold condenser
o Main circuit breaker tripping
o Check the main voltage
5.4 CL2 board :
Interconnection board
5.5 CL3 board :
Relay board :
- Main power
- Control for power Peltier, stepper motor and heating block transformer
- Relay circuit breaker tripping
5.6 CL4 board :
Interconnection board for Pt100 and thermocouple calibrations
5.7 CL56F et CL 56C boards :
Interconnection board :
- Between the process and MMi boards
- Between front panel and frame
