3.9.3 Replacement of the LCD display
Remove the side and rear panels (see above procedure 3.1.1)
Remove the front panel (see above procedure 3.1.2)
Tools
1 hex head key 2.5 mm
Remove the 2 fixing screws
Release the cable
Extract the LCD subset
