NORMALAB NDI 450 - Replacement of Drip Deflector Detector

NORMALAB France
2012
N O R M A L A B F r a n c e
19/118
3.2.4 Replacement of drip deflector detector
Tools
1 hex head key 3 mm
1 wrench 7mm
Remove the front panel (see above procedure 3.1.1)
Remove the roof of the receiver
compartment(2 hex screws)and extract it
(take care at the heating insulation)
Remove the flange around the condenser
Remove the optical sensor ( without
modifying the position adjustment)
Unplug the optical sensor cable
