NORMALAB NDI 450 - Replacement of the Cl3 Board

NORMALAB France
2012
N O R M A L A B F r a n c e
50/118
3.7.4 Replacement of the CL3 board
Remove the side and rear panels (see above procedure 3.1.1)
Tools
1 hex head key 5.5 mm
1 tube key 5.5 mm
1 wrench 12 mm
Remove the fixing supply frame
Remove the 2 ribbons of CL3 board
Unplug the wires of the board
Remove the 4 fixing nuts of the board
