3.3.5 Replacement the mechanical system of sample probe detection
Remove the left upper panel (see above procedure 3.1.1)
Tools
1 hex head key 2.5 mm
Remove the fixing screw
Take care at spring
3.3.6 Replacement of heating block door’s detector
Remove the front panel (see above procedure 3.1.2)
Tools
1 hex head key 2.5 mm
Position of the sensor
Remove the ribbon and the sensor
