N O R M A L A B F r a n c e
20/118
Remove the 2 maintaining scews
Remove the compartment probe
Lift the probe above condenser
Release the wires and turn the holder around the
condenser ( lift slightly the condenser tube)
Place the holder in front of condenser tube
to access by above
Loosen the maintaining screw
Vis de
maintien
capteur
Capteur
