Remove completely the screw and close the
hole to maintain the spring
Once the screws to release the spring, the sensor can
be extracted (mark the direction of the sensor)
Place the new sensor in the holder(the target
must be to the drip deflector)
Replace the medium in the slide, put the spring, push
the spring so that the screw can pass
Tighten the screw taking care the spring is
below
Check the mechanical operation with your drip
deflector
Connect the wires of the new one :
- Brown 7 of J3
- Black 8 of J3
- Blue 9 of J3
