N O R M A L A B F r a n c e
Latch for locking heating block door
Circulation pump for coolant circuit
Coolant circuit drain valve
Receiver compartment door hinge with spring
(pair)
Latch for locking test tube compartment door
Receiver compartment door
1st drip fork or follower spring
Magnet for follower position detect
Magnet for test tube compartment door
flask heating element sub-assembly with
thermocouple
Fluid circuit expansion chamber
