Hardware Recommendations:
Recommended Cables:
We recommend that the loop wiring should be wired in
2-core cables and each 2-core cable should be specific
to one function.
The RS485 Communications cable used should be rated
as suitable for up to 200mA in as short circuit condition.
Compatible SLC Devices:
Sensors Modules
CPX-551E Standard Ionisation Sensor M500KACGB Manual Call Point
CPX-751E Low Profile Ionisation Sensor M500KACW Weatherproof Manual Call Point
SDX-551E Standard Optical Sensor MMX-1E Monitor Module
SDX-751XXXX Low Profile Optical Sensor MMX-101E Mini Monitor Module
FDX-551XXX - Grade 2 Thermal Sensor; MMX-102E Micro Monitor Module
- High TemperatureThermal Sensor; MMX-10 10 Way Relay Module
- Grade 1 Rate of Rise Thermal Sensor ZMX-1 Conventional Zone Monitor Module
LPX-751 VIEW laser-based smoke sensor CMX-2E Control Module (Monitored or Relay)
HPX-751E HARSH Optical Sensor PS2-CMX Control Module With PSU and 2 Bell Circuits
IPX-751 Advanced MULTI Sensor CMX-10R 10 Way Relay Module
LPB-500 Loop Powered Beam Detector (TX/RX pair) ISO-X Standard Isolator Module
LBP-620/620R Loop Powered Beam Detector ISO524 Mini Isolator Module
IDX-751
1
HAZARD Intrinsically-safe smoke sensor MRM-1XXX Mains Relay Modules
B524IXXX - Sensor Base With Standard Isolator; ANS41 Addressable Loop Powered Sounder
- Sensor Base With FET Isolator; ANSE4 Addressable Externally Powered Sounder
- Sensor Base With Relay Output; ABS4
2
Addressable Loop Powered Sounder Base
HARSH Sensor Base ABSE4
2
Addressable Externally Powered Sounder
B501 Standard Sensor Base Base
IBS3 Addressable Loop Powered Base Sounder
with Built-in Sensor Base
AWS3
2
Addressable Loop Powered Wall Sounder.
1
Requires the Y72221 Isolation Unit
2
Colour options available
Some devices may be under development, Contact NOTIFIER for device availability
Cable Type Manufacturer Cable Name Type Number Application
Foil Screen Pirelli FP200 - All
Foil Screen Pirelli FP200 Gold - All
Foil Screen Draka Firetuf FTZ 2E1.5 All
Copper Clad BICC MICC CCM2L1.5RG All
Foil Screen H & S Radox FR Comms All
Foil Screen Draka - FDZ 1000 Data Comms
Foil Screen AEI Firetech F2C1.5E Data Comms
7/0.2 mm Arrow - 7-2-4S External RS232
4-core, screened (e.g. Printer)
