 Video Loss – used to setup the action settings when video loss is detected for this
camera. Press Settings (Mouse: Left click) to call up Video Loss Setup display for the
camera. Please refer to Section 6.1.3 for the details.
 Audio – the AUDIO IN corresponding to this camera. The audio data for the selected
AUDIO IN will be recorded with the video data for this camera. Select none (N/A) or
AUDIO Inputs (1-4) or “Camera” that means audio from IP-CAM. The default setting is
“N/A”.
Video Encode:
 Pattern – The Compression format for IP camera, please refer to Section 6.1.1 for the
details.
 Resolution – The Resolution for IP camera, please refer to Section 6.1.1 for the
details.
 Record Quality – The record quality for IP camera, please refer to Section 6.1.1 for
the details.
 Event Record IPS – the IPS (Images Per Second) for camera if certain event (Motion,
Alarm) occurs for this camera. This camera will be recorded at this rate for
Post-record time since the event occurs. For this NVR, Normal Record IPS are always
the same as Event Record IPS and Pre-record IPS.
 Pre-record IPS – the pre-record IPS for camera if certain event (Video Loss, Motion,
Alarm) occurs for this camera. This camera is recorded at this rate for Pre-record time
before the event occurs. For this NVR, Normal Record IPS are always the same as
Event Record IPS and Pre-record IPS.
 Normal Record IPS – the normal record IPS for camera. This camera will be recorded
at this rate if no event occurs. For this NVR, Normal Record IPS are always the same
as Event Record IPS and Pre-record IPS. The Normal Record IPS for IP camera, please
refer to Section 6.1.1 for the details.
 Actual Event Record IPS – the actual event record IPS set to the cameras because of
the limitation of the total system performance.
Detection:
 Type –“N/A” or “Motion” to enable motion detection of this camera. (Note: this field
has no effect for the Smart Search information.)
 Area/Privacy Mask – The settings are for motion detection and privacy mask settings.
Please refer to Section 6.1.4 for the details.
 Action – used to set up the Motion settings for Motion Detection. Press Action
(Mouse: Left click) to call up the Detection Action Setup display for the camera.
Please refer to Section 6.1.4 for the details.
Call By Event:
 Call By Event – whether to switch the monitor to the video of this camera if certain
event occurs for this camera. There are 4 options, including Off, Camera Event, Alarm,
Both (Camera Event & Alarm).
 Dwell Time – the dwell time if Call By Event is set to Camera Event, Alarm, or Both.
