Getting connected
A new standard modem is now set up
successfully on your PC, but you still need to
create a new dial-up connection:
1. Click Start > Settings > Control Panel
> Network and Dial-up Connections >
Make New Connection.
2. To continue, tap Next.
3. Select Dial-up to the Internet. Tap Next.
4. Enable the option I want to set up my
Internet connection manually, or I
want to connect through a local area
network (LAN) button, and Next.
5. Select I connect through a phone line
and a modem option, and then Next.
6. Enable the Use area code and dialing
rules checkbox and enter the telephone
number *99#, and then Next.
7. Enter the username and password you
use to log on to your ISP, and then click
Next.
8. Enter a name for this connection, and
then Next.
9. Select No when the installation wizard
asks you to set up an Internet mail
account, and then click Next.
10. After the installation is completed, click
Finish.
Connecting via USB Port
As with connection via USB Port, you need
to check the following before you start using
the Wireless Modem on your Xda Atom via
USB connection:
• Make sure that a GPRS enabled SIM
card is inserted in your Xda Atom.
• Disable the ActiveSync com port
connection of your PC.
• Disable the Infrared function by tapping
the Start menu > Settings > the
Connections tab > Beam, and then
uncheck Receive all incoming beams.
• Connect your Xda Atom to your PC USB
connection (using the USB sync cable).
Before setting up a USB modem, you must
verify that you have the two files, USBMDM
and USBModem_Dialer on the Companion
CD. Insert the Companion CD into the CD-
Rom of your PC and perform the settings as
follows:
1. Tap the Start menu > Programs >
Wireless Modem.
2. Select the USB connection type from the
drop-down list and insert the USB cable
adapter.
3. Tap the Start button on the Wireless
Modem screen of your Xda Atom.
4. A Found New Hardware message will
pop up on your desktop PC.
5. Select the Display a list of the known
drivers for this device so that I can
choose a specific driver option, and
then click Next.
6. Select Modem from the Hardware types
list, and then Next.
7. Click the Have Disk button, and then
Next.
