Commissioning/start-up
Pos: 216 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 217 /Alle Produk te/Warnhinweise/7. 1 ACHTUNG - Gerät nicht di mmen @ 13\mod_1258466348147_ 121.doc @ 82653 @ @ 1
Attention! Sensitive electrical components.
Possible consequence: The unit will be destroyed.
Protective measure: Do not connect the unit to a dimmable power supply.
Pos: 218 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 219 /Filter /FiltoClear 20000/300 00/Inbetriebnah me FiltClear 20000/30000 @ 21\mod_129259124940 5_121.doc @ 127220 @ @ 1
OASE recommends the use of BioKick CWS or BioKick fresh (OASE filter starter bacteria):
− For the initial start-up
− After manual cleaning of the foam filters
− After fitting new foam filters
− When recommissioning following a storage period/over-wintering
Prior to using filter starter bacteria ("Filter starter"), operate the unit for approx. 24 hours without switching on the UVC
unit. If you do not use filter starter bacteria, commissioning can start directly with the "Fitting connections" step.
How to proceed:
− Open the container (ÆCleaning and maintenance\Opening the container).
− Fill the filter starter bacteria (adhere to the attendant instructions for use!).
− Close the container (ÆCleaning and maintenance\Closing the container).
− Fit the connections (Æ Assembly).
− Check the firm seating of hoses, cover cap for soiled water drain, clamping ring with safety latch.
− Turn the function switch (J 5) to water filtering (40), if it is not already in this position.
− Switch on the pond pump.
− Only switch on the UVC unit when water is flowing through it. You may have to wait for 24 hours.
Connect power plug to the socket. The UVC unit switches on immediately, the blue LED (J 33) is lit.
Pos: 220 /Alle Produk te/Dummy_module/Abs tand 6 pt @ 7\mod_11966279 97106_0.doc @ 41651 @ @ 1
Pos: 221 /Alle Produk te/Überschrif ten/H1 Betrieb @ 10\mod_1250 187917601_121.doc @ 69200 @ @ 1
Operation
Pos: 222 /Alle Produk te/Betrieb/Betri eb bei unter 10 °C wirkungs los. UVC-Lampe nach 8000 Betri ebsstunden ersetzen @ 21\ mod_1292591596 985_121.doc @ 127247 @ @ 1
The unit is no longer biologically active at water temperatures below 10 °C. Take the unit out of operation at water
temperatures below 8 °C or, at the latest, when freezing temperatures are to be expected.
Normal operating condition: The UVC unit is switched on. The UV-C lamp must be replaced after approx. 8000 opera-
ting hours.
Pos: 223 /Alle Produk te/Dummy_module/Abs tand 6 pt @ 7\mod_11966279 97106_0.doc @ 41651 @ @ 1
Pos: 224 /Alle Produk te/Überschrif ten/H1 Störungsbesei tigung @ 7\mod_11966252 90699_121.doc @ 41521 @ @ 1
Remedy of faults
Pos: 225 /Filter /FiltoClear 20000/300 00/Störung Filtocle ar 20000/30000 @ 21\mod_1 292591901518_121. doc @ 127302 @ @ 1
Malfunction Cause Remedy
− Filter pump not switched on. − Switch on the filter pump
− Supply lines blocked. − Check supply lines
No water flow through the return
socket.
− Function switch not turned to "Filter water" − Turn function switch to „Filter water“
− Connection defective or has not been made. − Check connection (power plug, power fuse)
− Temperature monitor has switched off the UVC
lamp
− Allow the UVC lamp to cool down
− UVC lamp defective − Replace UVC lamp
UVC lamp display is not lit
− Quartz glass tube not fitted − Fit quartz glass tube
− Function switch not turned to "Filter water" − Turn function switch to „Filter water“
− Unit has not been in operation long enough
− Water extremely soiled
− Wait a few days/weeks
− Excessive fish and animal population − Adhere to the reference value
− Foam filters clogged − Clean foam filters
− Quartz glass tube soiled − Cleaning the quartz glass tube
Filtering performance not
satisfactory
− UVC lamp is in operation for more than 8000 hours − Replace UVC lamp
Pos: 226 /Alle Produk te/Dummy_module/Abs tand 6 pt @ 7\mod_11966279 97106_0.doc @ 41651 @ @ 1
Pos: 227 /Alle Produk te/Überschrif ten/H1 Verschleißtei le @ 8\mod_1223247075102_ 121.doc @ 53883 @ @ 1
Wear parts
Pos: 228 /Filter /Filtoclear 3000-150 00/Verschleißtei le Filtoclear @ 17\mod_1 268921649010_121.doc @ 110532 @ @ 1
The UVC lamp, the quartz glass and the foam filters are wear parts and are excluded from the warranty.
Pos: 229 /Alle Produk te/Dummy_module/= ==== Seitenwechsel = ==== @ 0\mod_1125648978015_ 0.doc @ 1631 @ @ 1

Oase FiltoClear 20000 Specifications

General

UV Clarifier	55 W
Dirt Outlet	Yes
Power Consumption UVC	55 W
Suitable for Ponds up to	20, 000 liters
Filter Type	Pressurized
Inlet/Outlet Size	1 1/2 inch
Weight	24 kg
