Maintenance and cleaning
Pos: 231 /Alle Produk te/Überschrif ten/H2 UVC-Gerätekopf ent nehmen/einsetzen @ 21\mod_1292594056536_ 121.doc @ 127357 @ @ 1
Removing/inserting the UVC unit head
Pos: 232 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 233 /Alle Produk te/Warnhinweise/E- ACHTUNG - Netzspannung a bsch. (vor Arbeitsbegi nn)# @ 15\mod_126398838 6870_121.doc @ 91183 @ @ 1
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Switch off the mains voltage prior to carrying out work on the unit.
Pos: 234 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 235 /Alle Produk te/Überschrif ten/H4 UVC-Gerätekopf ent nehmen @ 21\mod_129259 4170365_121.doc @ 127384 @ @ 1
Removing the UVC unit head
Pos: 236 /Alle Produk te/Bildbezeic hnungen/Bild (E) @ 21\ mod_1292581055286_121. doc @ 126422 @ @ 1
Figure (E)
Pos: 237 /Filter /FiltoClear 20000/300 00/UVC -Gerätekopf entn ehmen Filtoclear 2000 0/30000 @ 21\mod_12925942 87038_121.doc @ 127411 @ @ 1
How to proceed:
− Press the blue "Press" button (31) at the UVC unit head (4).
− Slightly turn the UVC unit head counter-clockwise.
− Carefully pull the UVC unit head out of the filter lid (8).
Pos: 238 /Alle Produk te/Überschrif ten/H4 UVC-Gerätekopf ei nsetzen @ 21\mod_129259 4406476_121.doc @ 12743 8 @ @ 1
Inserting the UVC unit head
Pos: 239 /Alle Produk te/Bildbezeic hnungen/Bild (F) @ 21\ mod_1292581056817_121. doc @ 126450 @ @ 1
Figure (F)
Pos: 240 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 241 /Filter /FiltoClear 20000/300 00/HINWEIS - O-Ring am UVC- Wassergehäuse @ 21\mod_1 292842677213_121. doc @ 128293 @ @ 1
Note!
The O ring (32) on the closure of the UVC water housing (4) is firmly clamped on. Only remove the O ring
when it must be replaced (e.g. when the O ring is porous).
Pos: 242 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 243 /Filter /FiltoClear 20000/300 00/UVC-Gerätekopf einsetzen FiltoClear 20000/30000 @ 21\mod_129 2594480742_121.doc @ 127465 @ @ 1
How to proceed:
− Carefully insert the UVC unit head (4) into the filter lid.
− Turn the UVC unit head clockwise up to the stop.
The blue "Press" button engages (31).
Pos: 244 /Alle Produk te/Überschrif ten/ H2 Behälter öffnen/ schließen @ 22\mod_12962 07681075_121.doc @ 128513 @ @ 1
Opening/ closing the container
Pos: 245 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 246 /Alle Produk te/Warnhinweise/E- ACHTUNG - Netzspannung a bsch. (vor Arbeitsbegi nn)# @ 15\mod_126398838 6870_121.doc @ 91183 @ @ 1
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Switch off the mains voltage prior to carrying out work on the unit.
Pos: 247 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 248 /Alle Produk te/Überschrif ten/H4 Behälter öffnen @ 21\mod_1292594609899_ 121.doc @ 127492 @ @ 1
Opening the container
Pos: 249 /Alle Produk te/Bildbezeic hnungen/Bild (G) @ 21\mod_12 92594706181_121.d oc @ 127546 @ @ 1
Figure (G)
Pos: 250 /Filter /FiltoClear 20000/300 00/Behälter öff nen FiltoClear 20000/3000 0 @ 21\mod_1292594885089_ 121.doc @ 127602 @ @ 1
How to proceed:
− Push back safety latch (36).
− Press the closing hook (35) inwards.
− Open and remove the clamping ring (10).
Pos: 251 /Alle Produk te/Überschrif ten/H4 Behälter schließe n @ 21\mod_1292594647915_ 121.doc @ 127519 @ @ 1
Closing the container
Pos: 252 /Alle Produk te/Bildbezeic hnungen/Bild (H, I) @ 21\ mod_1292594710728_121.d oc @ 127574 @ @ 1
Figure (H, I)
Pos: 253 /Filter /FiltoClear 20000/300 00/Behälter schließe n FiltoClear 20000/ 30000 @ 21\mod_1292595179 465_121.doc @ 127629 @ @ 1
How to proceed:
− Clean the channel (H 37) around the container rim.
− Grease the lid sealing ring (34) and place flush around the container (38) top edge.
− Press the filter lid (I 8) including the stack of foam filters on the container, if necessary, assist with your own body
weight.
− Place the clamping ring (10) around the container top edge (do not pinch the power cable) and assemble.
− Engage the closing hook (35).
− Push in the safety latch (36).
Pos: 254 /Alle Produk te/Überschrif ten/H2 Filterschwä mme reinigen @ 21\mod_129259 5342607_121.doc @ 127656 @ @ 1
Cleaning the foam filters
Pos: 255 /Alle Produk te/Reinigung/W artung/Easy Clean:Die Fi lterschwämme werden ger einigt durch Betätige n der Reinigungsgri ffe... @ 21\mod_129259 5576265_121.doc @ 127683 @ @ 1
The Easy-Clean function (actuate the cleaning handle and flush with water) allows easy cleaning of foam filters, UVC
unit and UVC water housing.
Pos: 256 /Alle Produk te/Bildbezeic hnungen/Bild (J, K, L) @ 21\mod_1292581058130_121. doc @ 126478 @ @ 1
Figure (J, K, L)
Pos: 257 /Filter /FiltoClear 20000/300 00/Filtersch wämme reinigen FiltoClear 2000 0/300000 @ 21\mod_12925 95813282_121.doc @ 127710 @ @ 1
How to proceed:
− Remove the closing cap from the drain hose or the dirty water drain socket (K 7). Attention: Do not lose the sealing
ring in the cap!
− Turn the function switch (5) counter-clockwise to "Cleaning foam filters" (41).

Oase FiltoClear 20000 Specifications

General

UV Clarifier	55 W
Dirt Outlet	Yes
Power Consumption UVC	55 W
Suitable for Ponds up to	20, 000 liters
Filter Type	Pressurized
Inlet/Outlet Size	1 1/2 inch
Weight	24 kg
