− Vigurously pull up the cleaning handle (3) several times, then push the handle down against the stop ("pumping"
action).
The foam filters will be rinsed by this action.
− As soon as only clean water appears in the transparent hose connector (20), turn the function switch (5) counter-
clockwise to "Cleaning UVC" (L 42).
The UVC unit and the UVC water housing are flushed.
− As soon as only clean water appears in the transparent hose connector (20), turn the function switch (5) counter-
clockwise to "Filter water" (J 40).
The unit filters the pond water.
− Close the drain hose or the soiled water drain socket (7) using the closing cap (insert sealing ring!) (C 9).
Pos: 258 /Alle Produk te/Überschrif ten/H2 Quarzglasrohr manuell reinigen @ 21\mod_1 292596014674_121. doc @ 127737 @ @ 1
Cleaning the quartz glass tube manually
Pos: 259 /Alle Produk te/Bildbezeic hnungen/Bild (E, F) @ 21\mod_1292581059192_121.doc @ 126506 @ @ 1
Figure (E, F)
Pos: 260 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 261 /Alle Produk te/Warnhinweise/E- ACHTUNG - Netzspannung a bsch. (vor Arbeitsbegi nn)# @ 15\mod_126398838 6870_121.doc @ 91183 @ @ 1
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Switch off the mains voltage prior to carrying out work on the unit.
Pos: 262 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 263 /Filter /FiltoClear 20000/300 00/Quarzglasrohr manuell reinigen FiltoC lear 20000/30000 @ 21\m od_1292596207269_12 1.doc @ 127764 @ @ 1
How to proceed:
− Switch off the filter pump.
− Remove the UVC unit head (ÆCleaning and maintenance\Removing/inserting the UVC unit head).
− Check the quartz glass tube (F 19) and O ring (32) for damage. Replace, if necessary.
− Clean the quartz glass tube externally using a moist cloth.
− Insert the UVC unit head (ÆCleaning and maintenance\Removing/inserting the UVC unit head).
− Switch on the filter pump.
− Switch on the UVC unit.
Pos: 264 /Alle Produk te/Überschrif ten/H2 Gerät reinigen und Fi lterschwämme waschen oder ersetzen @ 21\mod_129 2596459177_121.doc @ 127791 @ @ 1
Cleaning the unit and washing or replacing the foam filters
Pos: 265 /Alle Produk te/Reinigung/W artung/Filtersc hwämme altern und verschlei ßen @ 21\mod_12925965840 53_121.doc @ 127818 @ @ 1
Wear of the foam filters is caused by mechanical stress and normal ageing. OASE recommend: Replace old foam
filters with new ones at the beginning of the new season.
Pos: 266 /Alle Produk te/Bildbezeic hnungen/Bild (M,N,O) @ 21\ mod_1292581060255_12 1.doc @ 126534 @ @ 1
Figure (M, N, O)
Pos: 267 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 268 /Alle Produk te/Warnhinweise/E- ACHTUNG - Netzspannung a bsch. (vor Arbeitsbegi nn)# @ 15\mod_126398838 6870_121.doc @ 91183 @ @ 1
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Switch off the mains voltage prior to carrying out work on the unit.
Pos: 269 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 270 /Filter /FiltoClear 20000/300 00/Filtoclear 20000/ 30000 reinigen und Fil terschwämme waschen oder ersetzen @ 21\mod_12925 96906320_121.doc @ 127845 @ @ 1
How to proceed:
− Switch off the filter pump.
− Remove all hoses, hose connections (M).
− Remove the UVC unit head (4) (ÆCleaning and maintenance\Removing/inserting the UVC unit head).
− Open the container (ÆCleaning and maintenance\Opening the container).
− Remove the lid including the stack of foam filters (N 39) and place on a soft clean surface such that the fixing disk
(15) of the stack of foam filters faces upward.
Disassembling the foam filters
− Check the foam filters, and either wash or replace.
− Remove the filter disk (N 15) after loosening and removing the two screws (43).
− Pull off the foam filters.
Cleaning the parts
Figure B
− Clean the container, clamping ring, lid (remove UVC unit head!) including UVC water housing (18) and the meshed
tube (17) from all anlges with a strong water jet.
− If necessary, wash the foam filters individually by vigurously compressing and releasing the filters under running
water.
Assembling the foam filters:
Figure (P, Q)
− Alternately push the red (13) and then the blue (14) foam filter onto the cleaning rods (16), so that the cleaning rods
rest in the two cut-outs. The last foam filter (13) is a red one. A total of 7 red and 6 blue foam filters have to be as-
sembled.
− Place the fixing disk (15) on the last foam filter such that the end collar (44) points to the foam filters.
− Fasten the fixing disk on the cleaning rods using the two screws (Q 43).
− Reinstate all connections (Æ Assembly).
Pos: 271 /Alle Produk te/Dummy_module/= ==== Seitenwechsel = ==== @ 0\mod_1125648978015_ 0.doc @ 1631 @ @ 1

Oase FiltoClear 20000 Specifications

General

UV Clarifier	55 W
Dirt Outlet	Yes
Power Consumption UVC	55 W
Suitable for Ponds up to	20, 000 liters
Filter Type	Pressurized
Inlet/Outlet Size	1 1/2 inch
Weight	24 kg
