Replacing the UVC lamp
Pos: 273 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 274 /Alle Produk te/Warnhinweise/E- ACHTUNG - Netzspannung a bsch. und sich. ( vor Arbeitsbeginn)# @ 14\mod_1260 448661276_121.doc @ 87174 @ @ 1
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Isolate the unit prior to reaching into the water and carrying out any work on the unit.
Secure the unit from being switched on inadvertantly.
Pos: 275 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 276 /Alle Produk te/Warnhinweise/7. 7 ACHTUNG - Zerbrechli ches Glas @ 11\mod_12525741 81349_121.doc @ 73452 @ @ 1
Attention! Breakable glass.
Possible consequences: Injury of your hands caused by cuts.
Protective measures: Handle both quartz glass and UVC lamp with care.
Pos: 277 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 278 /Alle Produk te/Hinweise/UVC/ HINWEIS - UVC-Lampe bzw. Quar zglasrohr ersetzen @ 21\ mod_1292843218029_1 21.doc @ 128322 @ @ 1
Note!
Condensate forms in the quartz glass tube. This condensate cannot be avoided, however, it does not impair
function and safety.
The quartz glass tube can become scratched or blind over time. In this case, sufficient cleaning perform-
ance of the UVC lamp is no longer guaranteed. The quartz glass tube must be replaced.
The UVC lamp must be replaced after approx. 8000 operating hours. Only use UVC lamps the designation
and rating of which match the information on the type plate.
Pos: 279 /Alle Produk te/Dummy_module/Abs tand 3 pt @ 11\mod_1251901 846864_0.doc @ 72826 @ @ 1
Pos: 280 /Alle Produk te/Bildbezeic hnungen/ Bild (R, S, T, U, V) @ 21\ mod_1292581061286_121. doc @ 126562 @ @ 1
Figure (R, S, T, U, V)
Pos: 281 /Filter /FiltoClear 20000/300 00/FiltoClear 200 00/30000 UVC-Lampe erse tzen @ 21\mod_1292597427 362_121.doc @ 127899 @ @ 1
How to proceed:
Remove the UVC unit head (ÆRemoving/inserting the UVC unit head).
Clean the quartz glass tube (R 19) externally using a moist cloth.
Undo the fastening screw (46) from the retaining ring (45), and unscrew the retaining ring.
Remove the quartz glass tube including the O ring (S 47).
Pull the UVC lamp (T 49) out of the lamp base.
Pull the transport securing elements (48 and 50) from the UVC lamp and push over the new UVC lamp.
Insert the new UVC lamp.
Place the quartz glass tube (U 19) over the UVC lamp (49) again.
Push the O ring (47) and the retaining ring (45) over the quartz glass tube.
Tighten the retaining ring by turning it up against the stop (51).
Tighten the fastening screw (46) for the retaining ring (V).
Reinsert the UVC unit head (ÆRemoving/inserting the UVC unit head).
Switch on the pond pump.
Connect the power plug of the UVC unit.
Pos: 282 /Alle Produk te/Dummy_module/Abs tand 6 pt @ 7\mod_11966279 97106_0.doc @ 41651 @ @ 1
Pos: 283 /Alle Produk te/Überschrif ten/H1 Ausserbetri ebnahme/Lagern/Über wintern @ 21\mod_12925975 61816_121.doc @ 127926 @ @ 1
Decommissioning/Storage/Over-wintering
Pos: 284 /Alle Produk te/Lagern/Überwin tern/Filtergerä t mit UVC - Lagern/Überwin tern @ 21\mod_1292597804 833_121.doc @ 127953 @ @ 1
Empty/drain the container, hoses and connections as much as possible.
Clean thoroughly and check the unit for damage.
Remove, clean, and store the filter lid with the UVC unit and all filter elements in a dry and frost-free place.
Ensure that the storage place is inaccessible to children.
Secure the installation place of the buried container such that it does not pose any risk of accident for persons or
animals.
Pos: 285 /Alle Produk te/Dummy_module/Abs tand 6 pt @ 7\mod_11966279 97106_0.doc @ 41651 @ @ 1
Pos: 286 /Alle Produk te/Überschrif ten/H1 Entsorgung @ 21\mod_12 92597993428_121.doc @ 127980 @ @ 1
Disposal
Pos: 287 /Alle Produk te/Entsorgung/En tsorgung: Appell f ür umweltgerechtes Verha lten @ 21\mod_129259806221 0_121.doc @ 128007 @ @ 1
Support us in our endeavour to keep our environment intact, and adhere to the following disposal information!
Pos: 288 /Alle Produk te/Entsorgung/ TAB Entsorgung UVC, Elektr onik // Verpackung, Fi lterschwämme @ 21\mod_1292 598258274_121.do c @ 128034 @ @ 1
Use our return system for disposal. Always make electrical
units unusable by cutting the cables!
Disposal with the household waste:
UVC unit (electronics!) Packaging
UVC lamp (mercury!) Worn foam filters, sealing rings
Filter container
Pos: 289 /Alle Produk te/Dummy_module/= ==== Seitenwechsel = ==== @ 0\mod_1125648978015_ 0.doc @ 1630 @ @ 1
